Metal Bandsaw Blade WIKUS Primar 34-1.1-4335
WIKUS Primar 34-1.1-4335 is a high-quality bandsaw blade designed for precise and efficient metal cutting on industrial bandsaw machines. Thanks to its unique bimetallic construction and proven materials, this blade provides outstanding performance, durability, and flawless cutting quality.
Features and Advantages of WIKUS Primar 34-1.1-4335
- High-quality materials:
- Blade tooth: Made from high-quality **M42 high-speed steel**, which provides exceptional hardness up to **69 Rockwell units (HRC)**. This guarantees high wear resistance and maintains cutting edge sharpness even during intensive cutting of hard metals.
- Blade base: Made from durable **spring steel**, which gives the blade the necessary flexibility, tensile strength, and fatigue resistance, ensuring reliable and safe operation.
- Only variable tooth pitch: An important feature of WIKUS Primar is the presence of **exclusively variable tooth pitch**. This helps to minimize vibrations, optimize chip evacuation, and ensure a smoother and faster cut when processing various types of profiles and solid workpieces, which is not achievable with a constant pitch.
- Versatility of application: The blade is ideally suited for cutting a wide range of metals, including structural steels, stainless steels, tool steels, non-ferrous metals, and alloys.
- Increased productivity: Thanks to the combination of high-quality materials and optimal tooth geometry, the blade ensures high cutting speed and extended service life, which reduces production costs.
- Cutting precision: Provides a clean, straight, and precise cut, which is critically important for subsequent material processing.
Compatibility with machines (blade length 4335 mm)
This saw blade is ideally suited for use on the following bandsaw machine models of the "Myt" series, which can be purchased on our website:
- Bandsaw Machine «Myt 1-03»
- Bandsaw Machine «Myt 1-03P»
- Bandsaw Machine «Myt 1-03PA»
Available tooth pitches
For optimal selection for your production tasks, we have all popular variable tooth pitches available for WIKUS Primar 34-1.1-4335:
- 1.4/2 TPI
- 2/3 TPI
- 3/4 TPI
- 4/6 TPI
- 5/8 TPI
- 6/10 TPI
How to choose the right tooth pitch? Tooth pitch selection guide
Choosing the correct tooth pitch (TPI - Teeth Per Inch) is key for effective cutting, surface quality, and blade longevity. Use this table as a general guide for selecting the tooth pitch based on the size and type of workpiece. General rule: the smaller the workpiece/thinner the profile, the finer the tooth pitch; the larger the workpiece/solid material, the coarser the tooth pitch.
| Workpiece Diameter / Size (mm) |
Recommended Tooth Pitch (TPI) |
Purpose |
| Up to 40 mm (thin profiles, pipes, small workpieces) |
6/10 TPI |
For thin-walled pipes, profiles, and small solid workpieces. Provides a smooth cut and minimal vibrations. |
| 30 - 60 mm (medium profiles, thin-walled solids) |
5/8 TPI |
Universal pitch for medium profiles and small solid workpieces. Good balance between speed and quality. |
| 50 - 90 mm (medium workpieces, thick profiles) |
4/6 TPI |
For medium workpieces and thick profiles. Efficient chip evacuation and stable cut. |
| 80 - 150 mm (large workpieces, solids) |
3/4 TPI |
Ideal for large solid workpieces and bundle cutting. Provides high productivity. |
| 140 - 250 mm (very large solid workpieces) |
2/3 TPI |
For cutting very large solid workpieces where maximum cutting aggression and efficient evacuation of large amounts of chips are required. |
| 200 - 400 mm and more (extra-large workpieces, hard alloys) |
1.4/2 TPI |
The coarsest pitch, designed for the largest diameters of solid workpieces and particularly hard or difficult-to-machine materials, where maximum metal removal is needed. |
*Recommendations are general. The optimal tooth pitch choice may depend on the specific material (hardness, viscosity), desired surface quality, and cutting speed. In case of doubt, consult our specialists.
Technical Specifications
| Parameter |
Value |
| Blade Length |
4335 mm |
| Blade Width |
34 mm |
| Blade Thickness |
1.1 mm |
| Tooth Material |
M42 High-Speed Steel |
| Tooth Hardness |
69 HRC (Rockwell Hardness) |
| Blade Base Material |
Spring Steel |
| Tooth Pitch Type |
Variable Pitch |
| Manufacturer |
WIKUS (Germany) |
By choosing the WIKUS Primar 34-1.1-4335 bandsaw blade, you get German quality, high productivity, and durability for your metalworking production. Contact Hoper-Trade.com.ua to select the ideal blade for your tasks and purchase compatible "Myt" series machines.
